KNX RF USB Stick 340

This interface allows establishing a bidirectional connection between a PC or a laptop and the KNX RF wireless network. The device complies with the specification
of KNX RF and supports the protocol cEMI.

The interface is compatible with ETS 5 (or higher). For software integration (Windows or Linux) of this interface the free SDK kDrive express is available. The power is supplied via the USB port.

Technical Data

Mechanical data

• Housing: transparent plastic (ABS)
• Dimensions: 71 x 23 x 8.7 mm
• Weight: approx. 10 g

Power Supply

• USB <50 mA

Connectors

• USB: Connector male type A
  Max. cable length: 5 m
• Internal antenna

RF Interface

• KNX RF, ISM Band 868,3 MHz, FSK
• Output power: <10mW
