Multi IO Extension 590

The Multi IO Extension 590 serves as a power-saving alternative to commercial standard coupling relays. The coupling relay is controlled as a mono-stable relay, but uses a bi-stable relay internally, thus reducing the holding current by up to 95%.

The Multi IO Extension 590 has an integrated fuse to protect high-quality equipment.

Data sheet

Technical data

 Mechanical data

• Housing: plastic
• DIN rail mounted device, width: 1 modules (18 mm)
• Weigth: approx 50 g

Indicator and fuse

• LED (green) show relay state
• Glass fuse 5x20mm, 10 A

Connectors

• Screw terminal (2 poles) for 24 V⎓ input
• Screw terminal (3 poles) for 230 V∿ output

Input

• Input voltage (signal) 24 V⎓
• “Holding current” < 2 mA

Output

• Fuse 10 A
• Relay type: 250 V∿ / 16 A, bi-stable
  Depending on load type (capacitive or inductive) the switching power can be reduced significantly.

  Spare relays

 Standard relays for Multi IO Extension 590

• Art.-Nr. 5347
  EAN: 42 6026277 347 0
• Contact material: AgSnO2
• Input 24 V
• Output 230 V / 16 A, bi-stable
• Delivery unit: 10 pcs.

 Special relays for Multi IO Extension 590

• Art.-Nr. 5348
  EAN: 42 6026277 348 7
• Contact material: Tungsten / AgSnO2
• For high inrush currents, e.g. for LED lamps
• Input 24 V
• Output 230 V / 16 A, bi-stable
• Delivery unit: 10 pcs.

• Art.-Nr. 5349
  EAN: 42 6026277 349 4
• Contact material: AgSnO2
• For manual operation
• Input 24 V
• Output 230 V / 16 A, bi-stable
• Delivery unit: 10 pcs.
