The KNX DMX Gateway 544 is a compact gateway between KNX and DMX512 with up to 64 freely configurable channels. DMX is a protocol for lighting control, especially in stage technology.
In master mode, the device allows convenient control of DMX lights, for example with KNX push-buttons. Up to 64 dimming channels or up to 8 RGB/RGBW channels are available. Several subsets of DMX512 addresses can be assigned to each channel. The dimming channels enable switching /rel./abs. Dimming of one or more DMX devices via KNX. The RGB/RGBW channels enable the control of RGB/RGBW capable DMX devices. Each RGB colour and each HSV attribute can be individually controlled via KNX. Each channel can be linked with up to 8 scenes. In addition, 4 sequencers are available in the gateway to carry out more complex tasks.
