Power supply with choke
The power supply with high efficiency of the KNX IP LineMaster 762 provides a 29V bus voltage for the KNX system and an additional output with auxiliary voltage for supplying other devices. Special operating conditions such as short circuit, overvoltage, overload or overtemperature are logged and can be read off the display. The current current consumption is also displayed. A reset of the connected bus nodes is possible via the keypad.
KNX IP Router
The KNX IP LineMaster 762 integrated KNX IP router allows the transmission of telegrams to other lines via the LAN (IP) as a fast backbone (KNXnet/IP routing). The KNX IP LineMaster 762 thus also assumes the function of a KNX line coupler.
KNX IP Interface
The KNX IP LineMaster 762 can be used as an interface for bus access via IP. The KNX system can be configured and monitored from any PC in the LAN (KNXnet/IP tunnelling).
Technical data
Mechanical data
User Interface
Ethernet
KNX
Connectors
Plug for external power supply 230 V AC
Connector for KNX TP (red/black)
Connector for auxiliary power output (yellow/white)
LAN RJ-45 socket
