>RS-485 protocol
>Default IC (Mifare) card (“-D” means ID EM card)
>Support card, fingerprint
>Up to 4500 fingerprints capacity
>Blue backlight
>Watch dog function ensure device free from halting
>Beep and indicator
>Surface mounted installation
| Model |
ASR1102A/ASR1102A-D |
| System |
| Main Processor |
8 Bit |
| Capacity |
| Fingerprints |
4500 |
| Card Read |
| Read Format |
13.56MHz(Mifare)/125KHz(“-D” EM, Optional) |
| Read Range |
6-8cm (max.) |
| Response Time |
<0.1s |
| Fingerprint Read |
| Response Time |
≤0.5s |
| Recognition Time |
≤1.5s |
| FAR |
≤0.00004％ |
| FRR |
≤0.15％ |
| Function |
| Tamper Alarm |
Yes |
| Interface |
| To Controller |
RS485 |
| General |
| LCD Display |
Blue backlight |
| Beep Tone |
Buzzer |
| Ingress protection |
IP55 |
| Power Supply |
9-15VDC/100mA |
| Working Environment |
-5℃-+55℃ |
| Working Humidity |
5%~95% |
| Dimension(W×D×H) |
125mm*56mm*47mm |
| Weight |
0.25kg |
