>Wiegand(1000B) or RS-485 protocol(1100B)
>Default IC (Mifare) card (“-D” means ID EM card)
>Water-proof design
>Built-in 1 relay and can control door lock itself
>Watch dog function ensure device free from halting
>Beep and indicator
>Surface mounted installation
| Model |
ASR1100B/ ASR1100B-D |
ASR1000B/ ASR1000B-D |
| System |
| Main Processor |
8 Bit |
| Output port |
| Output |
Relay x 1(Door lock) |
| Read |
| Read Format |
13.56MHz(Mifare)/125KHz(“-D” EM, Optional) |
| Read Range |
6-8cm (max.) |
| Response time |
<0.1s |
| Function |
| Tamper Alarm |
Yes |
| Water-proof |
IP67 |
| Interface |
| To Controller |
RS485 |
Wiegand |
| General |
| LCD Display |
Blue backlight |
| Beep Tone |
Buzzer |
| Ingress protection |
IP55 |
| Power Supply |
9-15VDC/100mA |
| Working Environment |
-30℃-+60℃ |
| Working Humidity |
≤95% |
| Dimension(W×D×H) |
72mm*102mm*18mm |
| Weight |
0.2Kg |
